echnical Parameters:

	External size: 7.0mx5.6mx3.5m	Internal size: 6.9mx3.9mx2.7m
	Entrance Width: 3.0m	Entrance Height: 2.7m
	Fan capacity: 30000m/h	Air velocity: 0.3-0.5s/m
	Power: 25kw	Suitable Automobile Type:Car

Description:

• Wall panel: sandwich style, g=50mm, polystyrene.rock wool available as required.
• Basement: steel structure, full grids，ramp: 2 pcs of grids.
• Door: 3 pcs of front door without aluminum side cover. 1pcs of emergency door with pressure lock.
• Lengthen room as optional: outside size: 7.6*5.6*3.5(m)  inside size:7.5*3.9*2.7(m).
• One 11kw intake fan and one 11kw exhaust fan.
• 4m straight exhaust ducts, one 90° bend, and one 60° bend.5m straight chimney and 2 small bends.
• 1 manual VCD exhaust damper, electrical VCD as optional. one pressure meter.
• Spraying/baking transition damper, automatically air controlled.
• Heat exchanger: stainless steel. riello g20 burner.
• Roof filter: 6 pcs of filter, mounted above support frame, which is made of steel and powder coated.
• 5 pcs of floor filter and 2 pcs of outlet filter.
• Upper light: 10 sets, 4*40w per set. side lights: 8sets, 4*40w.
• Control box: imported components, overload, overheat, phase-lacking, phase-locking protection, engine  start.
• Automatically stop when preset time is up.
• Constant temperature spraying.
• Environmental filter :the equipment can be adopted m style activated carbon or drawer style activated carbon.
