Technical Parameters:

	External size: 8.7mx6.5mx4.2m	Internal size: 8.6mx4.0mx3.4m
	Entrance Width: 3.0m	Entrance Height: 3.5m
	Fan capacity: 35000m/h	Air velocity: 0.25-0.3s/m
	Power: 13kw	Suitable Automobile Type:  Mid-size-car

Description:

• Wall panel: sandwich style, g=50mm, polystyrene，rock wool available as required.
• Basement: steel structure, 3 rows of vein board and 2 rows of grids, full grids as optional.
• Door: 3 pcs of front door without aluminum side cover. 1pcs of emergency door with pressure lock.
• Basement: steel structure, 3 rows of vein board and 2 rows of grids, full grids as optional.
• Ramp: 2 pcs vein board.
• One 11kw intake fan.
• 5m straight exhaust ducts, one 90° bend, and one 60° bend.5m straight chimney and 2 small bends.
• Damper changer of painting and drying: changed automatically with cylinder-link driving.
• Heat exchanger: stainless steel. Riello/ G20S burner.
• Roof filter: 5 pcs of filter, mounted above support frame, which is made of steel and powder coated.
• 2 pcs of floor filter and 1 pcs of outlet filter.
• Upper light: 12 sets, 4*40w per set.
• Control box: imported components, overload, overheat, phase-lacking, phase-locking protection, engine start.
• Automatically stop when preset time is up.
• Constant temperature spraying.
