Technical Parameters:

	External size: 8.7mx6.5mx4.2m	Internal size: 8.6mx4.0mx3.4m
	Entrance Width: 3.0m	Entrance Height: 3.3m
	Fan capacity: 36000m/h	Air velocity: 0.25-0.35s/m
	Power: 22.5kw	Suitable Automobile Type: Mid-size bus

Description:

• Wall panel: sandwich style, g=50mm, polystyrene. rock wool available as required.
• Basement: steel structure, full grids. ramp: 2 pcs of grids.
• Door: 3 pcs of front door without aluminum side cover. 1pcs of emergency door with pressure lock.
• One 11kw intake fan and one 7.5kw exhaust fan.
• 5m straight exhaust ducts, one 90° bend, and one 60° bend.5m straight chimney and 2 small bends.
• Spraying/baking transition damper, automatically air controlled.
• Heat exchanger: stainless steel. riello g20s burner.
• Roof filter: 8 pcs of filter, mounted above support frame, which is made of steel and powder coated.
• 5 pcs of floor filter and 2 pcs of outlet filter.
• Upper light: 12 sets, 4*40w per set. side lights: 10sets, 4*40w.
• Control box: imported components, overload, overheat, phase-lacking, phase-locking protection, engine start.
• Automatically stop when preset time is up.
• Constant temperature spraying.
• Environmental filter :the equipment can be adopted m style activated carbon or drawer style activated carbon.
