Technical Parameters:

	External size: 7.0mx5.3mx3.4m	Internal size: 6.9mx3.9mx2.7m
	Entrance Width: 3.0m	Entrance Height: 2.7m
	Fan capacity: 17000m/h	Air velocity: 0.15-0.25s/m
	Air ventilation 332 times/h	Max Drying Temperature: 60℃-80℃
	Oil consumption: (L/unit) 6-8	Power: 7kw
	Suitable Automobile Type: Car

Description:

• One unit of 5.5kw European style fan gives excellect air capacity, low noise and high performance,
• The heat exchanger is completely made of stainless steel, comprising of a set of tubes which offers a wide exchange surface and high efficiency values.
• High pressure release door lock to for safety operation in spray booth.
• High efficiency Bairui burner.
• It gives time and tempera-ture of spraying and baking automa-tically. It has protection of over-heating, overload, and short-circuit.
• The filtering section is 2950mm width. Filters are put between frames and plenum structure, which guarantees a perfect tightness and avoids the non-filtered air leaking.
