Technical Parameters:

	Lifting height: 1300mm	Air: 6~8kg/cm
	Electricity power: 380V/50Hz	Capacity: 3000Kg
	Power: 2.2Kw

Description:

• This lift is especially used in painting and repairing devices in preparation area and spray booths where working height needs to be adjusted.
• Personnel can adjust the vehicle's height by lifting this lift according to different requirements, which decreases working intension and improves working effect.
• It is driven by single oil cylinder which avoiding non-synchronization.
• Arms are locked or unlocked by order switch automatically. Arms' angle, length and height can be adjusted to apply to different vehicles.
• Folded arms structure makes lift's initial height is the same as that of basement, which makes the lift preferred in low pan working.
• Pneumatic mechanical rack lock safety system makes it safe and reliable.
